【APM】NET Traces, Metrics and Logs to OLTP

news 来源：原创 2025/4/29 11:03:11

系列文章目录

【APM】Observability Solution

【APM】Build an environment for Traces, Metrics and Logs of App by OpenTelemetry

【APM】How to enable Trace to Logs on Grafana?

前言

前一篇分享了Observability（可观测性）环境的安装，本篇继续分享其应用。

一、Create a new project by NET

ASP.Net Core WebApi

二、PackageReference installation

Npgsql
Npgsql.EntityFrameworkCore.PostgreSQL
Npgsql.OpenTelemetry
OpenTelemetry.Exporter.Console
OpenTelemetry.Exporter.OpenTelemetryProtocol
OpenTelemetry.Extensions.Hosting
OpenTelemetry.Instrumentation.AspNetCore
OpenTelemetry.Instrumentation.Http
OpenTelemetry.Instrumentation.Runtime

三、Configure OpenTelemetry logging, metrics, & tracing

1.Program.cs

代码如下（示例）：

        private static readonly string ServiceName = typeof(Program).Namespace ?? "NetLog2Otlp";private static readonly string ServiceVersion = typeof(Program).Assembly.GetName().Version?.ToString() ?? "unknown";public static void Main(string[] args){var builder = WebApplication.CreateBuilder(args);#region Configure OpenTelemetry logging, metrics, & tracingstring otlpEndpoint = builder.Configuration.GetValue("Otlp:Endpoint", defaultValue: "http://localhost:4317");// Configure OpenTelemetry logging, metrics, & tracing with auto-start using the// AddOpenTelemetry extension from OpenTelemetry.Extensions.Hosting.builder.Services.AddOpenTelemetry().ConfigureResource(r => r.AddService(serviceName: ServiceName,serviceVersion: ServiceVersion,serviceInstanceId: Environment.MachineName)).WithTracing(_builder =>{// Tracing// Ensure the TracerProvider subscribes to any custom ActivitySources._builder.AddSource(InstrumentationSource.ActivitySourceName).SetSampler(new AlwaysOnSampler()).AddHttpClientInstrumentation()  // 监控 HttpClient 请求.AddAspNetCoreInstrumentation()  // 监控 ASP.NET Core 请求.AddNpgsql();                      // 监控 SQL 查询// Use IConfiguration binding for AspNetCore instrumentation options.builder.Services.Configure<AspNetCoreTraceInstrumentationOptions>(builder.Configuration.GetSection("AspNetCoreInstrumentation"));_builder.AddOtlpExporter(otlpOptions =>{// Use IConfiguration directly for Otlp exporter endpoint option.otlpOptions.Endpoint = new Uri(otlpEndpoint);});}).WithMetrics(_builder =>{// Metrics// Ensure the MeterProvider subscribes to any custom Meters._builder.AddMeter(InstrumentationSource.MeterName).SetExemplarFilter(ExemplarFilterType.TraceBased).AddRuntimeInstrumentation()     // 监控 .NET 运行时指标.AddHttpClientInstrumentation()  // 监控 HttpClient 请求.AddAspNetCoreInstrumentation(); // 监控 ASP.NET Core 请求_builder.AddOtlpExporter(otlpOptions =>{// Use IConfiguration directly for Otlp exporter endpoint option.otlpOptions.Endpoint = new Uri(otlpEndpoint);});}).WithLogging(_builder =>{// Note: See appsettings.json Logging:OpenTelemetry section for configuration._builder.AddOtlpExporter(otlpOptions =>{// Use IConfiguration directly for Otlp exporter endpoint option.otlpOptions.Endpoint = new Uri(otlpEndpoint);}).AddConsoleExporter();});#endregion// Add services to the container....

2.appsettings.json

代码如下（示例）：

{"Logging": {"LogLevel": {"Default": "Warning","Microsoft": "Warning","Microsoft.AspNetCore": "Warning","Microsoft.Hosting.Lifetime": "Warning","System": "Warning","NetLog2Otlp": "Information"},"OpenTelemetry": {"IncludeFormattedMessage": true,"IncludeScopes": true,"ParseStateValues": true}},"Otlp": {"Endpoint": "http://localhost:4317"},"AspNetCoreInstrumentation": {"RecordException": "true"},"AllowedHosts": "*"
}

3.InstrumentationSource.cs

namespace NetLog2Otlp.AspNetCore;using System.Diagnostics;
using System.Diagnostics.Metrics;/// <summary>
/// It is recommended to use a custom type to hold references for
/// ActivitySource and Instruments. This avoids possible type collisions
/// with other components in the DI container.
/// </summary>
public sealed class InstrumentationSource : IDisposable
{internal const string ActivitySourceName = "NetLog2Otlp.AspNetCore";internal const string MeterName = "NetLog2Otlp.AspNetCore";private readonly Meter meter;public InstrumentationSource(){string? version = typeof(InstrumentationSource).Assembly.GetName().Version?.ToString();this.ActivitySource = new ActivitySource(ActivitySourceName, version);this.meter = new Meter(MeterName, version);this.FreezingDaysCounter = this.meter.CreateCounter<long>("weather.days.freezing", description: "The number of days where the temperature is below freezing");}public ActivitySource ActivitySource { get; }public Counter<long> FreezingDaysCounter { get; }public void Dispose(){this.ActivitySource.Dispose();this.meter.Dispose();}
}

4.OtlpController.cs

using Microsoft.AspNetCore.Mvc;
using Npgsql;
using System.Collections.Generic;
using System.Reflection.Emit;
using Microsoft.EntityFrameworkCore;// For more information on enabling Web API for empty projects, visit https://go.microsoft.com/fwlink/?LinkID=397860namespace NetLog2Otlp.Controllers
{[Route("api/[controller]")][ApiController]public class OtlpController : ControllerBase{private readonly ILogger<OtlpController> _logger;// 使用依赖注入获取 Loggerpublic OtlpController(ILogger<OtlpController> logger){_logger = logger;}// GET: api/<OtlpController>[HttpGet]public IEnumerable<string> Get(){_logger.LogInformation("Start logging at {time}", DateTime.Now);try{ExecuteSql();_logger.LogInformation(" ExecuteSql finished at {time}", DateTime.Now);ExecuteEF();_logger.LogInformation(" ExecuteEF finished at {time}", DateTime.Now);HttpRequest();_logger.LogInformation(" Test API called at {time}", DateTime.Now);int i = 0;var j = i / 0; // This will throw a divide by zero exception}catch (Exception ex){_logger.LogError(ex, " An error occurred during the logging process.");}finally{_logger.LogInformation("End logging at {time}", DateTime.Now);}return new string[] { "value1", "value2", DateTime.Now.ToString() };}// GET api/<OtlpController>/5[HttpGet("{id}")]public string Get(int id = 0){_logger.LogDebug("LogDebug");_logger.LogInformation("LogInformation");_logger.LogWarning("LogWarning");_logger.LogError("LogError");_logger.LogInformation("Get by id API called at {time}, id: {id}", DateTime.Now, id.ToString());return string.Format("value: {0}", id.ToString());}void ExecuteSql(){// PostgreSQL 连接字符串var connectionString = "Host=192.168.1.1;Port=5432;Username=user;Password=user;Database=TestDB";// 使用 Npgsql 连接到 PostgreSQL 数据库using (var connection = new NpgsqlConnection(connectionString)){connection.Open();// 创建查询命令using (var command = new NpgsqlCommand("SELECT * FROM test1", connection)){// 执行查询并读取结果using (var reader = command.ExecuteReader()){while (reader.Read()){// 假设你的表中有列 "id" 和 "name"string id = reader.GetString(0); // 获取第一列的值string name = reader.GetString(1); // 获取第二列的值Console.WriteLine($"ID: {id}, Name: {name}");}}}}}void ExecuteEF(){using (var context = new MyDbContext()){// Read all entriesvar entities = context.MyEntities.ToList();// Create a new entryvar newEntity = new MyEntity { apid = "ExecuteEF", name = "New Entity", site = "*", url = "*" };context.MyEntities.Add(newEntity);context.SaveChanges();// Update an entryvar entity = context.MyEntities.Where(o => o.apid == "ExecuteEF").FirstOrDefault();if (entity.apid != null){entity.name = "Updated Name";context.SaveChanges();}// Delete an entrycontext.MyEntities.Remove(entity);context.SaveChanges();}}async void HttpRequest(){try{// 這裡替換成你要請求的 URLstring url = "https://www.baidu.com";using (var client = new HttpClient()){HttpResponseMessage response = await client.GetAsync(url);response.EnsureSuccessStatusCode();  // 會拋出異常如果 HTTP 請求不成功string responseBody = await response.Content.ReadAsStringAsync();Console.WriteLine(responseBody);}}catch (HttpRequestException e){Console.WriteLine("Request error: {0}", e.Message);}}}public class MyDbContext : DbContext{public MyDbContext(){}public MyDbContext(DbContextOptions<MyDbContext> options): base(options){}// Define DbSet for each entity in your database schemapublic DbSet<MyEntity> MyEntities { get; set; }protected override void OnConfiguring(DbContextOptionsBuilder optionsBuilder){// PostgreSQL 连接字符串var connectionString = "Host=192.168.1.1;Port=5432;Username=user;Password=user;Database=TestDB";// Configure PostgreSQL as the database provideroptionsBuilder.UseNpgsql(connectionString);}protected override void OnModelCreating(ModelBuilder modelBuilder){modelBuilder.Entity<MyEntity>().HasKey(e => e.apid);  // 指定主鍵是 apid 屬性modelBuilder.Entity<MyEntity>().ToTable("test1"); // 將 MyEntity 對應到名為 "test1" 的資料庫表}}public class MyEntity{public string apid { get; set; }public string name { get; set; }public string url { get; set; }public string site { get; set; }}}
