通过阿里云Milvus与通义千问VL大模型，快速实现多模态搜索

news 来源：原创 2025/4/25 7:09:01

本文主要演示了如何使用阿里云向量检索服务Milvus版与通义千问VL大模型，提取图片特征，并使用多模态Embedding模型，快速实现多模态搜索。

基于灵积（Dashscope）模型服务上的通义千问 API以及Embedding API来接入图片、文本等非结构化数据Embedding为向量的能力。

通义千问VL大模型介绍《通义千问VL API详情》

通义多模态向量模型介绍《Multimodal-Embedding API详情》

前提条件

已创建阿里云Milvus实例。具体操作，请参见快速创建Milvus实例。
已开通服务并获得API-KEY。具体操作，请参见开通DashScope并创建API-KEY。

该示例的运行环境为python3.9

python3 -m pip install dashscope pymilvus==2.5.0

wget https://github.com/milvus-io/pymilvus-assets/releases/download/imagedata/reverse_image_search.zip
unzip -q -o reverse_image_search.zip

示例代码

在本文示例中，我们先将示例图片通过通义千问VL提取图片描述，存储在image_description中，然后将图片描述和图片通过多模态Embedding模型分别转换为向量存储在image_embedding和text_embedding中。

备注：在该示例中，仅以数据集前200张图片作为演示

import base64
import csv
import dashscope
import os
import pandas as pd
import sys
import time
from tqdm import tqdm
from pymilvus import (connections,FieldSchema,CollectionSchema,DataType,Collection,MilvusException,utility,
)from http import HTTPStatus
import logginglogging.basicConfig(level=logging.INFO)

数据准备

if __name__ == "__main__":MILVUS_HOST = "c-xxxxxxxxxxxx.milvus.aliyuncs.com"MILVUS_PORT = "19530"MILVUS_TOKEN = "root:password"COLLECTION_NAME = "multimodal_search"INDEX = "IVF_FLAT" # IVF_FLAT OR HNSW# Step1：初始化Milvus客户端milvus_client = MilvusClient(MILVUS_TOKEN, MILVUS_HOST, MILVUS_PORT, INDEX, COLLECTION_NAME)DASHSCOPE_API_KEY = ""# Step2：初始化千问VL大模型与多模态Embedding模型extractor = FeatureExtractor(DASHSCOPE_API_KEY)extractorVL = FeatureExtractorVL(DASHSCOPE_API_KEY)# Step3：将图片数据集Embedding后插入到Milvusembeddings = load_image_embeddings(extractor, extractorVL, "reverse_image_search.csv")milvus_client.insert(embeddings)

在Step1中将Collection创建完成后，可以在控制台登录Attu，查看Collection Schema信息，如下图所示。

在完成Step3后，可以在Attu中查看插入数据，此时图片数据已经过通义千问VL大模型提取描述特征，并Embedding为向量。

可以看出下图经过通义千问VL大模型提取后，文本总结为“站在海滩上的人穿着牛仔裤和绿色靴子。沙滩上有水迹覆盖。关键词：海滩、脚印、沙地、鞋子、裤子”，用文字非常形象的描述了这张图片的特征。

图：jean/n03594734_9714.JPEG

多模态量检索：以文搜图

在下面这个这个示例中，查询文本query为"棕色的狗"，将query通过多模态向量模型Embedding以后，分别在image_embedding和text_embedding上进行以文搜图和以文搜文，可以得到不同的检索结果。

注意：由于大模型产出结果存在一定的随机性，本示例结果可能无法完全一致的复现。

if __name__ == "__main__":MILVUS_HOST = "c-xxxxxxxxxxxx.milvus.aliyuncs.com"MILVUS_PORT = "19530"MILVUS_TOKEN = "root:password"COLLECTION_NAME = "multimodal_search"INDEX = "IVF_FLAT" # IVF_FLAT OR HNSW# Step1：初始化Milvus客户端milvus_client = MilvusClient(MILVUS_TOKEN, MILVUS_HOST, MILVUS_PORT, INDEX, COLLECTION_NAME)DASHSCOPE_API_KEY = ""# Step2：初始化多模态Embedding模型extractor = FeatureExtractor(DASHSCOPE_API_KEY)# Step4：多模态搜索示例，以文搜图和以文搜文text_query = "棕色的狗"text_embedding = extractor(text_query, "text")text_results_1 = milvus_client.search(text_embedding, feild = 'image_embedding')logger.info(f"以文搜图查询结果: {text_results_1}")text_results_2 = milvus_client.search(text_embedding, feild = 'text_embedding')logger.info(f"以文搜文查询结果: {text_results_2}")"""
以文搜图查询结果
{'id': 457336885198973657, 'distance': 1.338853359222412, 'origin': './train/Rhodesian_ridgeback/n02087394_9675.JPEG', 'image_description': '一张小狗站在地毯上的照片。它有着棕色的毛发和蓝色的眼睛。\n关键词：小狗、地毯、眼睛、毛色、站立'},
{'id': 457336885198973648, 'distance': 1.3568601608276367, 'origin': './train/Rhodesian_ridgeback/n02087394_6382.JPEG', 'image_description': '这是一只棕色的猎犬，耳朵垂下，脖子上戴着项圈。它正直视前方。\n\n关键词：狗、棕色、猎犬、耳朵、项链'},
{'id': 457336885198973655, 'distance': 1.3838427066802979, 'origin': './train/Rhodesian_ridgeback/n02087394_5846.JPEG', 'image_description': '两只小狗在毛毯上玩耍。一只狗躺在另一只上面，背景中有一个玩具熊。\n\n关键词：小狗、玩闹、毛毯、玩具熊、互动'}
""""""
以文搜文查询结果
[{'id': 457336885198973739, 'distance': 0.6969608068466187, 'origin': './train/mongoose/n02137549_7552.JPEG', 'image_description': '这是一张棕色的小动物的特写照片。它有着圆润的脸庞和大大的眼睛。\n\n关键词：小动物、棕毛、圆形脸、大眼、自然背景'},
{'id': 457336885198973648, 'distance': 0.7110348343849182, 'origin': './train/Rhodesian_ridgeback/n02087394_6382.JPEG', 'image_description': '这是一只棕色的猎犬，耳朵垂下，脖子上戴着项圈。它正直视前方。\n\n关键词：狗、棕色、猎犬、耳朵、项链'},
{'id': 457336885198973707, 'distance': 0.7725887298583984, 'origin': './train/lion/n02129165_19310.JPEG', 'image_description': '这是一张狮子的特写照片。它有着浓密的鬃毛和锐利的眼神。\n\n关键词：狮子、眼神、鬃毛、自然环境、野生动物'}
"""

多模态向量检索：以图搜文

在下面这个这个示例中，我们使用test中的狮子图片进行相似性检索，分别进行以图搜图和以图搜文。

图：lion/n02129165_13728.JPEG

注意：由于大模型产出结果存在一定的随机性，本示例结果可能无法完全一致的复现。

if __name__ == "__main__":MILVUS_HOST = "c-xxxxxxxxxxxx.milvus.aliyuncs.com"MILVUS_PORT = "19530"MILVUS_TOKEN = "root:password"COLLECTION_NAME = "multimodal_search"INDEX = "IVF_FLAT" # IVF_FLAT OR HNSW# Step1：初始化Milvus客户端milvus_client = MilvusClient(MILVUS_TOKEN, MILVUS_HOST, MILVUS_PORT, INDEX, COLLECTION_NAME)DASHSCOPE_API_KEY = ""# Step2：初始化多模态Embedding模型extractor = FeatureExtractor(DASHSCOPE_API_KEY)# Step5：多模态搜索示例，以图搜图和以图搜文image_query_path = "./test/lion/n02129165_13728.JPEG"image_embedding = extractor(image_query_path, "image")image_results_1 = milvus_client.search(image_embedding, feild = 'image_embedding')logger.info(f"以图搜图查询结果: {image_results_1}")image_results_2 = milvus_client.search(image_embedding, feild = 'text_embedding')logger.info(f"以图搜文查询结果: {image_results_2}")"""
以图搜图查询结果
{'id': 457336885198973702, 'distance': 0.23892249166965485, 'origin': './train/lion/n02129165_19953.JPEG', 'image_description': '这是一只雄壮的狮子站在岩石旁，背景是树木和灌木丛。阳光洒在它的身上。\n\n关键词：狮子、岩石、森林、阳光、野性'},
{'id': 457336885198973704, 'distance': 0.4113130569458008, 'origin': './train/lion/n02129165_1142.JPEG', 'image_description': '一只狮子在茂密的绿色植物中休息。背景是竹子和树木。\n\n关键词：狮子、草地、绿植、树干、自然环境'},
{'id': 457336885198973699, 'distance': 0.5206397175788879, 'origin': './train/lion/n02129165_16.JPEG', 'image_description': '图中是一对狮子在草地上站立。雄狮鬃毛浓密，雌狮则显得更为瘦弱。\n\n关键词：狮子、草地、雄性、雌性、自然环境'}
""""""
以图搜文查询结果
{'id': 457336885198973704, 'distance': 1.0935896635055542, 'origin': './train/lion/n02129165_1142.JPEG', 'image_description': '一只狮子在茂密的绿色植物中休息。背景是竹子和树木。\n\n关键词：狮子、草地、绿植、树干、自然环境'},
{'id': 457336885198973702, 'distance': 1.2102885246276855, 'origin': './train/lion/n02129165_19953.JPEG', 'image_description': '这是一只雄壮的狮子站在岩石旁，背景是树木和灌木丛。阳光洒在它的身上。\n\n关键词：狮子、岩石、森林、阳光、野性'},
{'id': 457336885198973707, 'distance': 1.2725986242294312, 'origin': './train/lion/n02129165_19310.JPEG', 'image_description': '这是一张狮子的特写照片。它有着浓密的鬃毛和锐利的眼神。\n\n关键词：狮子、眼神、鬃毛、自然环境、野生动物'}
"""

import base64
import csv
import dashscope
import os
import pandas as pd
import sys
import time
from tqdm import tqdm
from pymilvus import (connections,FieldSchema,CollectionSchema,DataType,Collection,MilvusException,utility
)
from http import HTTPStatus
import logginglogging.basicConfig(level=logging.INFO)
