OAuth2AuthorizationEndpointFilter类介绍、应用场景和示例代码

news 来源：原创 2025/4/29 6:42:02

概述

OAuth2AuthorizationEndpointFilter 是 Spring Security OAuth2 授权服务器中的核心过滤器，负责处理 OAuth2 授权码授权流程中的 /oauth2/authorize 端点请求。

核心功能

处理授权请求：验证客户端发起的授权请求参数
用户同意流程：处理用户对授权范围的同意操作
生成授权码：验证通过后生成授权码返回给客户端
错误处理：处理授权过程中的各种错误情况

主要组件和工作流程

1. 请求匹配

使用 RequestMatcher 匹配 /oauth2/authorize 端点的 GET 和 POST 请求
区分授权请求和同意请求：
- 授权请求：包含 response_type 参数
- 同意请求：不包含 response_type 参数

2. 认证转换器

默认使用 DelegatingAuthenticationConverter 组合两个转换器：
- OAuth2AuthorizationCodeRequestAuthenticationConverter：转换授权请求
- OAuth2AuthorizationConsentAuthenticationConverter：转换同意请求

3. 认证管理器

使用 AuthenticationManager 处理认证逻辑
默认配置了两个认证提供者：
- OAuth2AuthorizationCodeRequestAuthenticationProvider：处理授权请求
- OAuth2AuthorizationConsentAuthenticationProvider：处理同意请求

4. 成功/失败处理器

authenticationSuccessHandler：处理成功认证，默认发送授权响应
authenticationFailureHandler：处理认证失败，默认发送错误响应

5. 同意页面

consentPage：配置自定义同意页面URI

工作流程

匹配请求路径和方法
使用认证转换器将请求转换为认证对象
使用认证管理器进行认证
处理认证结果：
- 成功：生成授权码并重定向回客户端
- 需要用户同意：重定向到同意页面
- 失败：返回错误信息

应用场景

标准授权码流程：处理客户端发起的授权请求
自定义同意页面：替换默认的同意页面
扩展授权流程：通过自定义转换器或处理器实现特殊业务逻辑
OpenID Connect：处理包含 openid 范围的请求

示例代码

基本配置示例

@Configuration
@EnableWebSecurity
public class AuthorizationServerConfig {@Bean@Order(Ordered.HIGHEST_PRECEDENCE)public SecurityFilterChain authorizationServerSecurityFilterChain(HttpSecurity http) throws Exception {OAuth2AuthorizationServerConfigurer authorizationServerConfigurer =new OAuth2AuthorizationServerConfigurer();http.apply(authorizationServerConfigurer).authorizationEndpoint(authorizationEndpoint -> authorizationEndpoint.consentPage("/oauth2/consent") // 自定义同意页面);return http.build();}
}

自定义同意页面示例

@Controller
public class ConsentController {@GetMapping("/oauth2/consent")public String consent(@RequestParam(OAuth2ParameterNames.SCOPE) String scope,@RequestParam(OAuth2ParameterNames.CLIENT_ID) String clientId,@RequestParam(OAuth2ParameterNames.STATE) String state,Model model) {// 查询客户端信息RegisteredClient registeredClient = registeredClientRepository.findByClientId(clientId);// 解析scopeSet<String> scopes = StringUtils.delimitedListToSet(scope, " ");model.addAttribute("clientId", clientId);model.addAttribute("state", state);model.addAttribute("scopes", scopes);model.addAttribute("clientName", registeredClient.getClientName());return "consent";}@PostMapping("/oauth2/consent")public String approveOrDeny(@RequestParam(OAuth2ParameterNames.SCOPE) String scope,@RequestParam(OAuth2ParameterNames.CLIENT_ID) String clientId,@RequestParam(OAuth2ParameterNames.STATE) String state,@RequestParam String userAction) {if ("approve".equals(userAction)) {// 用户同意授权return "redirect:/oauth2/authorize?" +"client_id=" + clientId +"&state=" + state +"&scope=" + scope;} else {// 用户拒绝授权return "redirect:/oauth2/authorize?" +"client_id=" + clientId +"&state=" + state +"&error=access_denied";}}
}

自定义认证转换器示例

@Bean
@Order(Ordered.HIGHEST_PRECEDENCE)
public SecurityFilterChain authorizationServerSecurityFilterChain(HttpSecurity http) throws Exception {OAuth2AuthorizationServerConfigurer authorizationServerConfigurer =new OAuth2AuthorizationServerConfigurer();http.apply(authorizationServerConfigurer).authorizationEndpoint(authorizationEndpoint -> authorizationEndpoint.authenticationConverter(new CustomAuthenticationConverter()));return http.build();
}// 自定义认证转换器
static class CustomAuthenticationConverter implements AuthenticationConverter {@Overridepublic Authentication convert(HttpServletRequest request) {// 自定义转换逻辑if (request.getParameter("custom_param") != null) {// 处理自定义参数return new CustomAuthenticationToken(request);}// 默认处理return new OAuth2AuthorizationCodeRequestAuthenticationConverter().convert(request);}
}

自定义成功处理器示例

@Bean
@Order(Ordered.HIGHEST_PRECEDENCE)
public SecurityFilterChain authorizationServerSecurityFilterChain(HttpSecurity http) throws Exception {OAuth2AuthorizationServerConfigurer authorizationServerConfigurer =new OAuth2AuthorizationServerConfigurer();http.apply(authorizationServerConfigurer).authorizationEndpoint(authorizationEndpoint -> authorizationEndpoint.authorizationResponseHandler(new CustomAuthorizationResponseHandler()));return http.build();
}// 自定义成功处理器
static class CustomAuthorizationResponseHandler implements AuthenticationSuccessHandler {private final RedirectStrategy redirectStrategy = new DefaultRedirectStrategy();@Overridepublic void onAuthenticationSuccess(HttpServletRequest request, HttpServletResponse response,Authentication authentication) throws IOException {OAuth2AuthorizationCodeRequestAuthenticationToken authorizationCodeRequestAuthentication =(OAuth2AuthorizationCodeRequestAuthenticationToken) authentication;// 记录授权日志logAuthorization(authorizationCodeRequestAuthentication);// 构建标准响应UriComponentsBuilder uriBuilder = UriComponentsBuilder.fromUriString(authorizationCodeRequestAuthentication.getRedirectUri()).queryParam(OAuth2ParameterNames.CODE,authorizationCodeRequestAuthentication.getAuthorizationCode().getTokenValue());if (StringUtils.hasText(authorizationCodeRequestAuthentication.getState())) {uriBuilder.queryParam(OAuth2ParameterNames.STATE,UriUtils.encode(authorizationCodeRequestAuthentication.getState(), StandardCharsets.UTF_8));}String redirectUri = uriBuilder.build(true).toUriString();this.redirectStrategy.sendRedirect(request, response, redirectUri);}private void logAuthorization(OAuth2AuthorizationCodeRequestAuthenticationToken authentication) {// 实现日志记录逻辑}
}
